Description
Sulzer Medium-consistency products SX chemical mixer -Brings excellence into the mixing
Key Technical Specifications:
| Capacities | Up to 550 l/s / 8’700 US gpm |
| Pressures | Up to 25 bar / 360 psi |
| Temperatures | Up to 180 °C / 355 °F |
| Discharge sizes | From from 150 mm / 6 in to 350 mm / 14 in |
| Maximum speed of rotation | Up to 1 800 rpm |
Why Choose This Product?
The Sulzer SX chemical mixer is engineered for efficient, uniform chemical distribution in medium-consistency pulp processes. It improves reaction efficiency , enhances pulp quality , and minimizes chemical consumption , all within a compact and reliable design.
Key Technical Specifications
Type: Inline medium-consistency chemical mixer
Consistency Range: Up to 16%
Material: Stainless steel or corrosion-resistant alloys
Mixing Element: High-intensity , low-shear design for gentle yet thorough mixing
Maintenance: Minimal servicing required due to no moving parts
Operating Limits
Medium: Pulp suspension with process chemicals
Temperature: Suited for standard pulp mill conditions
Pressure Drop: Low, enabling energy savings
Typical Applications
Bleaching chemical dosing
Additive mixing for pulp property enhancement
pH control in pulp processing
Retention aid and filler distribution
Additional Features
Inline installation for easy integration
Consistent mixing performance
Energy-efficient operation
Long service life with minimal wear
