Description
Burckhardt Compression Laby® 2K250 – Ultra-Robust Oil-Free Compressor for Demanding Gas Applications
Key Technical Specifications
Compressor Type: Laby® 2K250
Cranks: 2
Stroke: 250 mm / 9.8 in
Max. Speed: 500 rpm
Rated Power: 1’660 kW / 2’226 hp
Width: 970 mm / 38 in
Height: 3’570 mm / 141 in
Length: 2’310 mm / 91 in
Weight: ~18’300 kg / 40’300 lbs
Design Standards: API 618, ISO 13707, ATEX Certified
Sealing Technology: Labyrinth (non-contact, oil-free)
Why Choose the Burckhardt Laby® 2K250?
Built for demanding, high-capacity gas compression with zero oil contamination , the 2K250 delivers strong , reliable performance in tough industrial settings.
Oil-Free Compression – Non – lubricated labyrinth seals keep gas pure
High Power – Large stroke and horsepower for maximum throughput
Handles Harsh Conditions – Stable with dry , wet , or cryogenic gases
Long-Lasting – Designed for low wear and minimal maintenance
Certified Safe -Meets ATEX and API 618 standards worldwide
Applications
LNG / LPG Loading & Storage
Ammonia, Methanol & Fertilizer Plants
Marine & Offshore Gas Compression
Petrochemical & Gas Recovery
Cryogenic Transfer Systems
Air Separation & Specialty Gases
Natural Gas Pipeline Boosting
Additional Features
Labyrinth seals reduce friction and extend life
Oil-free cylinders ensure ultra – pure gas handling
Customizable for plant – specific needs
High-capacity design built for reliability and uptime
Optimize your high – demand gas compression with the Burckhardt Compression Laby® 2K250 – where high capacity meets oil – free purity.
