Description
Burckhardt Compression Laby® 2K158 – High – Capacity, Oil – Free Compressor for Demanding Gas Applications
Key Technical Specifications
Compressor Type: Laby® 2K158
Cranks: 2
Stroke: 158 mm / 6.2 in
Max. Speed: 750 rpm
Rated Power: 485 kW / 665 hp
Width: 910 mm / 36 in
Height: 2’340 mm / 92 in
Length: 1’600 mm / 63 in
Weight: 5’800 kg / 12’700 lbs
Design Standards: API 618, ISO 13707 , ATEX Certified
Compression Technology: Labyrinth – sealed , oil – free , single – acting piston compressor
Why Choose the Burckhardt Laby® 2K158?
The 2K158 is built for tough gas compression tasks where purity and reliability are non – negotiable.
With oil – free sealing and a rugged , low – maintenance design , it’s ideal for continuous use in demanding environments.
Oil-Free Labyrinth Seals – Keeps gas clean and pure
Up to 485 kW Power – Strong performance for industrial needs
Built to Last – Durable frame for nonstop operation
Low Maintenance – Fewer wear parts mean less downtime
ATEX Certified – Safe for use in explosive zones
Applications
Hydrogen & helium compression
LNG & marine fueling systems
Pharma & fine chemical processes
Industrial gas filling
Cryogenic & research labs
Key Features
Dry-running design – No oil, no contamination
Vertical footprint – Saves space in compact setups
API 618 compliant – Trusted for mission – critical systems
Quiet & stable – Low vibration , smooth operation
Engineered for purity , reliability , and performance – the Burckhardt Laby® 2K158 is your trusted solution for high – capacity gas compression.
