Description

Burckhardt Compression CC Air-Cooled Compressor – Compact & Efficient High-Pressure Gas Compression

Key Technical Specifications:

• Compressor Type: CC (Air-cooled, trunk piston)

• Stroke: 100 mm

• Maximum Speed: 1,365 rpm

• Rated Power: 45 kW

• Dimensions (W x H x L): 1,250 mm x 1,415 mm x 1,900 mm

• Weight: 1,350 kg

Why Choose the CC Air-Cooled Compressor?

Compact. Efficient. Built to Perform.
The CC air-cooled gas compressor offers high compression performance in a small, robust package—perfect for remote sites and space-limited industrial setups.

Quick Setup, Minimal Maintenance
Factory-tested and skid-mounted, it arrives ready to run. With fewer moving parts, built-in auto condensate drains, and anti-vibration mounts, it keeps downtime and service needs low.

Key Features

• Air-cooled system with automatic condensate drainage

• Anti-vibration mounts for smooth, long-lasting operation

• Trunk piston design ideal for light gases

• Concentric valves for steady, efficient flow

• Available in “W” and inverted “T” cylinder options

Compatible Gases
Hydrogen, Helium, Nitrogen, Argon, Natural Gas, Compressed Air, Breathing Air

Typical Applications
CNG / NGV fueling stations, industrial gas bottling, hydrogen processing, argon and helium recovery, fertilizer and energy plants

Proven Performance. Global Trust.
The CC air-cooled compressor from Burckhardt Compression is a trusted choice for gas compression, fuel refilling, and clean energy operations worldwide.
